    Dock leveller AMTRK-PRO

    Dock leveller AMTRK-PRO

    30 September 2020 Dock levellers Leave a comment
    Leave review
    Intended use

    The swing lip dock leveller is designed for picking up pallets with a forklift to load or unload trucks. The leveller is equipped with a stable hinged plate that ensures quick and safe loading. The leveller has the CE mark. Its platform is made of 6/8 mm thick ribbed sheet metal. It is integrated with the service support and connected to the back of the leveller frame with hinges. Fully secure use is ensured by the anti-slip surface, foot protection along the entire length of the platform and the full lifting range of the leveller. Different methods of placing bridges in the foundation are possible.

    Application Nominal
    Loading systems
    Lengths Nominal
    2000, 2500, 3000, 3500, 4000 mm
    Widths Structure
    2000, 2250 mm
    Construction height
    610 mm
    Nominal lip lengths Sheet metal
    400, 500 mm
    Sheet metal thickness
    (depending on the load capacity)
    Nominal load capacity
    6-12 tonnes (60-120 kN)
    Working ranges above the level
    0 to 430 mm
    Standard colours
    RAL 9005 RAL 7042 RAL 5010 (two-component resin-based paint)
    Tank capacity
    6 dm3
    Working pressure
    140 bar
    Motor power
    1,1 kW
    Supply voltage
    230/400 V AC
    Control voltage
    24 V DC
    Protection type
    IP54
    Operating medium
    TELLUS T-15 or RANDO HDZ-15 mineral oil
    Control
    • the drive system of the leveller is a hydraulic cylinder,
    • the lip is lifted by a separate cylinder, powered separately by a hydraulic unit,
    • closed hydraulic system (maximum pressure 22 bar),
    • smooth adjustment to the vehicle height during loading,
    • single-button control,
    • protection in the event of a power failure or the use of an emergency switch, the leveller is protected against fall – it will stop and maintain the position it was in at the moment,
    • the leveller control system can be coupled with the gate control system.
    Dock pan

    The main function of the pan is to connect the leveller with the dock. The pan is directly filled with concrete.

    Product datasheet
    Download
    Read More
    Loading platform AMTR-I

    Loading platform AMTR-I

    30 September 2020 Bridges and plates Leave a comment
    Leave review
    Intended use

    The mechanical AMTR-I bridge is designed for use in all kinds of industrial facilities where an additional docking system is required. It is recommended primarily for logistics facilities where there is a continuous flow of goods.

    Standard colours
    RAL 9005 RAL 7042 RAL 5010 (two-component resin-based paint)
    Heights
    550-650 mm
    Width
    1200-2600 mm
    Product datasheet
    Download
    Read More
